Rated capacities(Emax)	1, 1.5, 2, 2.5t
Sensitivity	3.0± 0.003mV/V
Creep error (30min)	±0.02% F.S.
Zero balance	± 1% F.S.
TCO (Temperature Coefficient of Offset)	± 0.02%F.S. /10°C
TC SPAN (Temperature Coefficient of Span)	± 0.02%F.S. /10°C
Input impedance	400 ± 20 Ω
Output impedance	352 ± 3 Ω
Insulation impedance	≥5000 MΩ (50V DC)
Temperature range, compensated	-10°C ~ +40°C
Temperature range, operating	-30°C ~ +70°C
Maximum safe overload	150% F.S.
Ultimate overload	180% F.F.
Excitation, recommend	10V ~ 12V DC
Excitation maximum	15V DC
Protection class	IP68
Construction	Alloy Steel or Stainless Steel
Cable diameter	⌀5mm, 4 core
Cable Length	3m
